- Type: n-channel
- Drain-to-Source Breakdown Voltage: 55 V
- Gate-to-Source Voltage, max: ±20 V
- Drain-Source On-State Resistance, max: 8 mΩ
- Continuous Drain Current: 98 A
- Total Gate Charge: 97.3 nC
- Power Dissipation: 150 W
- Package: TO-220AB
Irf3205 Mosfet Datasheet
You can replace the IRF3205 with the IRF1405, IRF1405Z, IRF1407, IRF1607, IRF2805, IRF2907Z, IRF3205Z, IRF3305, IRF3808, IRFB3006, IRFB3006G, IRFB3077, IRFB3077G, IRFB3206, IRFB3206G, IRFB3207, IRFB3207Z, IRFB3207ZG, IRFB3256, IRFB3306, IRFB3306G, IRFB3307, IRFB3307Z, IRFB4110, IRFB4110G, IRFB4310, IRFB4310G, IRFB4310Z, IRFB4310ZG
Irf3205 Mosfet
(JimmyM suggests a switch to 2.2k and 5k for the IRF2804 MOSFET - it will switch faster and thus reduce the heat generated during turn on and off) Alternative MOSFETs are the 24V 1324 (?24V Ref) or if voltage won't exceed 30V the IRLR7843 (Ref.JimmyM) or 40V with IRF3206. Infineon irf3205 MOSFET are available at Mouser Electronics. Mouser offers inventory, pricing, & datasheets for Infineon irf3205 MOSFET. IRFB3206PBF, datasheet for IRFB3206PBF - HEXFET Power MOSFET provided by International Rectifier. IRFB3206PBF pdf documentation and IRFB3206PBF application notes, selection guide. MOSFET is an electronic devices with good switching characteristics. It is widely used in circuits, such as power supplies switching,motor drives, lighting dimmer and so on.
